For cotton, wool, hemp, silk, rayon, and chemical short fibers, and other processes such as rovings and spun yarns.
1. Modular design, easy maintenance and strong expansion performance.
2, advanced computer control technology, WINDOWS operating system testing software, easy to learn.
3, using the most advanced sensor detection circuit, the detection signal is more accurate and stable.
4. The traction mechanism is double-driven and the sliver does not slip.
5, roller size, low speed, unique shock absorber design, smooth transmission.
6, roller automatically open and close, automatic expansion and contraction, and can be used to reduce the yarn to wear and prolong life.
7. The spectrogram can show the wavelength value, and the uneven graph can be arbitrarily scaled to facilitate analysis.
8, a powerful database search function.
9, test software free upgrades.
|
|
|
|
Provide single-tube yarn spectrogram, uneven curve, offset rate threshold curve, line density frequency distribution, variation length curve, comprehensive statistical analysis, a set of statistical spectrogram, a set of statistical variation length curve, 4 files All squat values, AF values, 2nd-level DR statistics, U-values, 5th CVm values, CVb, Q95%, and kilometer statistics.
|
|
|
|
|
|
|
|
Test principle
|
Capacitive testing
|
|
Test scope
|
4tex-80Ktex
|
|
Test slot
|
5
|
|
Test speed
|
4, 8, 25, 50, 100, 200, 400m/min
|
|
Test time
|
Multiple files are arbitrarily set, with a minimum of 0.5 minute and a maximum of 50 minutes.
|
|
Proportional scale
|
12.5%, 25%, 50%, 100%
|
|
CV% test range
|
0.00-99.99%, cutting length range:0-100m
|
|
Offset rate (DR%) test range
|
0.00-99.99%
|
|
Popup
|
Normal and Fine Types
|
|
Number of channels
|
85 (Ordinary)/170 (Fine)
|
|
Maximum test length
|
10000m
|
|
Defect sensitivity
|
Details: -30%, -40%, -50%, -60%
Thick section: +35%, +50%, +70%, +100%
Cotton (hair) knot Nep: +140%, +200%, +280%, +400%
|
|
|
|
